dsh-plugin-garmin-connect

A TypeScript-based Garmin Connect plugin and MCP server with secure browser-based MFA, built for DeepSeek Harness and designed to work with other AI agents.

npm version npm downloads CI Test Report Node.js License: MIT

English 简体中文 Test Report Changelog

DeepSeek Harness, WorkBuddy, Qwen Work, ZCode, Claude Code, Codex, Cursor, and Windsurf

Works with mainstream coding agents and AI workspaces
DeepSeek Harness · WorkBuddy · Qwen Work · ZCode · Claude Code · Codex · Cursor · Windsurf
Connect through MCP or a SKILL.md workflow, depending on the client.

[!NOTE] MFA support in 0.1.6: local dsh Web, the garmin-connect-auth serve system-browser flow, and MCP URL elicitation can bootstrap the same owner-only session for China and International accounts. Real-account MFA completed in both regions on 2026-08-29, including a full China-region browser-to-session-and-read chain and an International-region system-browser DI exchange with owner-only session persistence. Browser policy may still block an individual flow. The older login --browser command is retained only as a diagnostic.

More Apps

Icon App What it does
WristTale WristTale Read TXT and Markdown on your Garmin watch
JiaKe.app JiaKe.app Turn Garmin screenshots into polished assets
GameraSnap GameraSnap Control your phone camera from your Garmin watch
WristAlbum WristAlbum Keep a private photo album on your Garmin
WristPass WristPass Keep cards and tickets ready on your wrist
2FA4G 2FA4G Keep offline 2FA codes on your Garmin

What It Does

This plugin connects DeepSeek Harness or any MCP-compatible AI agent to Garmin Connect, exposing your wearable data as AI-callable tools. Once installed, the agent can automatically query your activities, sleep, steps, and heart rate to provide personalized fitness insights — all through natural language.

Registered Tools

The plugin registers 10 tools. Eight return Garmin data without writing; download_garmin_activity_fit writes one local file on the MCP/dsh host, and create_garmin_workout changes the user’s Garmin workout library.

Tool Description Example Args
get_garmin_activities Fetch recent activities (runs, rides, swims…) with compact or full detail {"limit": 5, "detail": "compact"}
get_garmin_sleep Sleep score, duration, and stage breakdown for a date or range {"startDate": "2023-10-01", "endDate": "2023-10-02"}
get_garmin_steps Step totals for a date or range; goal/distance appear only when Garmin supplies them {"startDate": "2023-10-01"}
get_garmin_heart_rate Resting, max, and min heart rate for a date or range {"startDate": "2023-10-01", "endDate": "2023-10-02"}
get_garmin_weight Body composition (weight, BMI, body fat %, muscle mass, etc.) for a date or range {"startDate": "2023-10-01"}
get_garmin_workouts Workout templates from your Garmin workout library (not calendar scheduling) {"limit": 10, "offset": 0}
get_garmin_profile User profile summary {} or omit
get_running_skill_advice Explain 8 workout types and 4 training philosophies, or collect the mandatory intake for personalized coaching {"mode": "explain", "query": "Daniels", "language": "en"}
download_garmin_activity_fit Download an activity’s original archive and safely extract its single FIT file to the account directory under the configured host parent {"activityId": 123456789}
create_garmin_workout Preview a structured workout; create it only after explicit confirmation {"name": "Threshold 3×8min", "steps": [...]}

Workout creation is a two-call flow. The preview response includes a one-time confirmationId; after the user approves the unchanged preview, call the tool again with the same definition, confirmed: true, and that confirmationId. An ID expires after 10 minutes and cannot be reused.

Personalized running coaching

get_running_skill_advice deliberately separates explanation from planning:

Intake field What the assistant must ask
goal Target distance/event, future ISO YYYY-MM-DD date, and completion or ideal/minimum time goal
currentPerformance + performanceBasis A representative race/time trial from the past two years, result, non-future date, effort/conditions, or an explicit no_recent_benchmark
trainingBackground Running history and recent 4–8 week volume, frequency, long run, quality work, and interruptions
availability Available days/time, fixed rest and long-run days, terrain/facility limits, strength-training time, and whether double days are possible
healthConstraints + hasWarningSymptoms Current/past-year injury, pain, relevant disease/medication, sleep and recovery, plus an explicit warning-symptom boolean
trainingPreference + preference details steady, hard_easy, or mixed, plus maxQualitySessionsPerWeek (0–7) and intensityGuidancePreference (pace, heart_rate, rpe, or mixed)

If hasWarningSymptoms is true—for example current chest discomfort, unusual breathlessness with mild activity, fainting/dizziness, or abnormal palpitations—the tool returns a safety stop without workout material or Garmin activity access. It advises medical clearance and does not diagnose. If performanceBasis is no_recent_benchmark, planning material instructs the assistant to begin with easy base work or a low-risk benchmark instead of inventing precise threshold or interval paces.

The compact philosophy layer contains:

Recent Garmin runs may supplement this intake but never replace the athlete’s answers. The method notes and evidence boundaries are summarized in the training-method research note. Each philosophy and workout-card output labels its statements as system_principle, research_evidence, or application_inference so a method definition or coaching inference is not misrepresented as comparative proof.

Quick Start

1. Install this plugin — from the npm registry (recommended)

npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add dsh-plugin-garmin-connect

This single command installs the dependency and activates the plugin layer — the first run automatically initializes the web profile. You only need pnpm on your PATH:

npm install -g pnpm

--legacy-peer-deps=false makes npm resolve peer dependencies normally. If your npm config has legacy-peer-deps=true (it skips peer packages), dsh would fail to boot with ERR_MODULE_NOT_FOUND: Cannot find package '@deepseek-ai/cordis-plugin-group'. On machines without that setting the flag is a harmless no-op.

Verify the plugin layer is composed without booting:

npx --legacy-peer-deps=false @deepseek-ai/dsh --profile web --dump-config | grep -A 2 garmin-connect

Other install sources:

# Local checkout (development)
cd garmin-connect-plugin-for-dsh && npm install
npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add .

# GitHub source install
npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add github:<owner>/<repo>

2. Install the Harness CLI (if you haven’t already)

npx --legacy-peer-deps=false @deepseek-ai/dsh web

The web UI starts at http://127.0.0.1:3080 by default. If you launch Harness via npx, keep using the same prefix for the commands below (npx --legacy-peer-deps=false @deepseek-ai/dsh …); if you have dsh installed globally, you can drop the npx @deepseek-ai/ prefix.

3. Configure Credentials

Normal runtime credentials come from environment variables (or a secret store provided by your launcher); keep .env out of version control. The local Web MFA flow is the narrow exception: after explicit profile confirmation, the Host atomically saves an owner-only DI session file. It never saves the password, MFA code, or CAPTCHA response.

# Source checkout only: copy the bundled template
cp .env.example .env

# Edit .env and fill in your Garmin credentials

For a registry installation, create .env directly in the directory where you run dsh (your workspace root), then add the variables from the table below; the package’s template is inside the installed dependency rather than your current directory. The plugin loads the workspace .env automatically.

Variable Required Description
GARMIN_USERNAME ✅ Your Garmin account email
GARMIN_ACCOUNT ❌ Lowercase local alias used for the implicit Web/CLI/MCP session path (default when omitted)
GARMIN_PASSWORD ✅* Legacy direct-login password; do not use this for the interactive MFA setup below
GARMIN_SESSION_TOKEN ✅* Inline pre-authenticated token (supported, but the session file is safer)
GARMIN_SESSION_TOKEN_FILE ✅* Path to the owner-only DI v2 (or compatible legacy OAuth) session file generated by the local auth command
GARMIN_REGION ❌ global (default) or cn for Garmin China
GARMIN_FIT_DOWNLOAD_DIR FIT only User-selected host parent directory for FIT exports; no default. The generated account directory includes GARMIN_REGION
GARMIN_CACHE_TTL ❌ Cache duration in seconds (default: 300)
GARMIN_REQUEST_TIMEOUT_MS ❌ Garmin request timeout in milliseconds (default: 15000)
GARMIN_LOG_LEVEL ❌ debug | info | warn | error
GARMIN_ACTIVITY_DETAIL ❌ compact (default) or full (expanded fitness plus precise route/location fields; credentials and account/social identifiers are filtered)

* Normal data access needs one of GARMIN_PASSWORD, GARMIN_SESSION_TOKEN, or GARMIN_SESSION_TOKEN_FILE. The local Web, auth:serve, and standalone MCP flows may start without one and create the implicit account session file. A protected file is safer than an inline token, especially when isolating multiple processes. If more than one is configured, the inline token takes precedence over the file until Garmin explicitly rejects it; a newly written, account-matching session file can then take over on retry. A valid session takes precedence over password login.

⚠️ If your password contains # or other special characters, wrap it in double quotes — otherwise # and everything after it will be treated as a comment:

GARMIN_PASSWORD="my#secret!pass"

GARMIN_SESSION_TOKEN and the contents of GARMIN_SESSION_TOKEN_FILE are as sensitive as a password. Token export is intentionally not AI-callable; never paste a token into an AI conversation.

Two-step verification — browser-based MFA

When dsh and its Web UI are running together on the same local machine, use the China account or International account Garmin button in the top bar. The selected button must match the process’s configured GARMIN_REGION; a mismatch fails before any Garmin page is opened. A matching selection opens a custom bridge on an ephemeral 127.0.0.1 port; that bridge, rather than the dsh page itself, embeds Garmin’s official GAuth page. Email, password, MFA code, and any CAPTCHA are entered only inside the Garmin iframe.

Making this safe and reliable required more than adding a verification-code field. We first kept Garmin’s official GAuth page inside a local iframe so the email, password, and MFA code stayed on Garmin’s origin, then worked through cross-origin messaging, missing vendor styles, browser CSP/Trusted Types, third-party-frame policy, MFA redirects, and exact ticket/service binding. Inspired by Zhitao’s DailySync approach of completing Garmin SSO in a fresh browser tab, we added the system-browser loopback broker used by CLI and MCP clients. The tab returns only a short-lived, one-time service ticket; the Host immediately exchanges it for the longer-lived DI session and refresh credentials, verifies the Garmin profile, and writes an owner-only session. In other words, the ticket itself is not a one-year credential—the potentially long-lived artifact is the exchanged session/refresh credential, whose actual lifetime remains controlled by Garmin.

Garmin sends its short-lived service ticket only to the isolated loopback bridge. The bridge validates the expected region, message origin, iframe source, service, and ticket, then immediately hands it to the plugin Host for the region-bound DI token exchange. Garmin China may bind an MFA ticket to the exact current http://127.0.0.1:<port> bridge instead of the fixed Garmin embed URL; the plugin preserves that ticket/service pair unchanged and rejects every other loopback host, port, path, query, or region before contacting DI. It never rewrites or retries the one-time ticket with a fallback service. The Host probes the Garmin profile, shows a sanitized profile to the user, and asks them to confirm that it corresponds to the configured email. Only then does it atomically save an owner-only session bound to the configured account and region. The outer dsh page receives only public progress states: the dsh page, model context, and AI-callable tool results never receive the ticket, DI token, password, MFA code, or CAPTCHA response.

After the Host verifies the account through password login, a profile-bound DI session, or a newly confirmed Web login, the matching region button subtitle shows the verified account email as signed in; the other region keeps its domain. Merely loading an identity-unverified legacy OAuth token does not show this state, and the status endpoint never returns a ticket or token. The local page refreshes this state every 15 seconds and whenever the window regains focus, so later credential rejection or a successful lazy login updates the subtitle.

When the Host reports a missing, expired, or rejected session, or password login returns positive MFA/CAPTCHA page evidence, the local page automatically opens the configured region’s auth dialog once. Closing it does not reopen the same requirement revision; only a new state can trigger another automatic open. The SDK’s ambiguous no-ticket text, a password HTTP 401, generic sign-in HTML, network errors, and MFA-looking titles do not trigger browser authentication. While unauthenticated, the page polls this coarse data-free state once per second; after login it returns to the 15-second account refresh.

Configure GARMIN_USERNAME and the correct GARMIN_REGION before opening the dialog. GARMIN_SESSION_TOKEN_FILE is optional for this Web flow: when omitted, the Host uses GARMIN_ACCOUNT (default default) and writes ~/.config/dsh-plugin-garmin-connect/accounts/<alias>.session.json on the usual POSIX configuration path (or the platform configuration root). After a confirmed write, the running plugin clears any earlier rejected-session state; the next tool call reads the new file without requiring a dsh restart.

This supported Web flow is intentionally limited to the loopback dsh Web UI. It is not a remote, hosted, or tunneled login endpoint. Browser third-party-cookie and iframe policies can prevent Garmin GAuth from completing. A real China-region MFA run passed the browser, DI exchange, profile confirmation, owner-only persistence, and read-only session-consumption chain locally on 2026-08-29. A real International-region MFA run also passed the system-browser challenge, DI exchange, profile confirmation, and owner-only session persistence. This does not turn the same-machine flow into a remote or indefinite session-recovery guarantee. Login, MFA, and profile confirmation must finish within the bridge’s 10-minute lifetime.

See the target architecture for two-step verification for the complete trust boundary and data flow.

Local system-browser authentication

The recommended local MFA flow for CLI and MCP clients is the loopback broker. Choose the account alias and region explicitly. For this command, both flags are required and GARMIN_ACCOUNT/GARMIN_REGION are deliberately not used as defaults, preventing a two-account setup from writing the wrong session:

# Installed executable
garmin-connect-auth serve --account personal --region global --open
garmin-connect-auth serve --account personal-cn --region cn --open

# Source checkout
npm run auth:serve -- --account personal --region global
npm run auth:serve -- --account personal-cn --region cn

serve starts a one-shot bridge on a random 127.0.0.1 port and opens it in the system’s default browser. It does not create or manage an isolated Chrome/Playwright profile; the operating system may reuse an already-running browser or start the configured default browser. The CLI may read the configured account email, but the password, MFA code, and any CAPTCHA remain on Garmin’s page; they cannot be supplied through flags, environment variables, MCP tool arguments, or model input. The bridge receives only the short-lived service ticket and hands it to the local runtime for the region-bound DI exchange. The page then displays a sanitized profile for confirmation before the runtime writes the owner-only session. Login, MFA, and profile confirmation must finish within 10 minutes; after that, start a new flow.

When GARMIN_SESSION_TOKEN_FILE is omitted, the output path is derived from GARMIN_ACCOUNT/--account: ~/.config/dsh-plugin-garmin-connect/accounts/<alias>.session.json on the usual POSIX configuration path (or the platform configuration root). The process can then use only the non-password configuration below:

[email protected]
GARMIN_ACCOUNT=personal
GARMIN_REGION=global
GARMIN_FIT_DOWNLOAD_DIR=/absolute/path/to/garmin-fit-parent

This browser bootstrap is release-supported for same-machine authentication in both regions. Real China-region and International-region MFA runs passed locally on 2026-08-29. Real refresh-token rotation remains part of ongoing compatibility coverage rather than a limitation on MFA support.

Legacy browser diagnostics

garmin-connect-auth login --browser is retained only for development and diagnosis; it is not the recommended fallback for serve or MCP authentication. It launches an isolated Chrome context through Playwright and may encounter redirect interception failures. The non-persisting canary exercises the same legacy path:

garmin-connect-auth login --browser --account personal --region global
garmin-connect-auth login --browser --account personal-cn --region cn
npm run auth:canary -- --region global
npm run auth:canary -- --region cn

The direct terminal-password attempt without --browser remains for compatibility. Leaving its password prompt blank opens the shared system-browser flow; positive MFA/CAPTCHA page evidence switches to that same flow without asking for a terminal MFA code. Ambiguous password, network, and no-ticket failures do not auto-open a browser. These diagnostics are separate from the supported system-browser MFA bootstrap.

DI v2 files bind the normalized username, region, and probed Garmin profile via one-way hashes, including profileIdHash; they do not duplicate the plaintext email in the binding. The runtime rejects username, region, or profile mismatch before publishing refreshed credentials. It refreshes access tokens before expiry, persists a rotated refresh token before using the new session, and may retry an authentication failure at most once for an idempotent GET. Workout and other write requests are never replayed automatically.

For backward compatibility, legacy session files containing only the two oauth1 and oauth2 fields are still accepted. They have no profile binding; the intended replacement is a browser-generated, validated DI v2 session with the mismatch guard. On POSIX, a legacy file must still pass the current owner-only file-permission check (normally mode 0600), complete safe ancestor-chain validation, and a private final-parent check (normally mode 0700).

On POSIX, the default account directory is prepared before Garmin authentication opens. To choose a different session file, add --output /absolute/private/path/personal.session.json. Preflight canonicalizes any safe existing link target, rejects unsafe/writable ancestors, requires the final parent to belong to the effective UID with owner write+execute and no group/other access (normally mode 0700), and creates missing components one at a time as 0700. The writer uses that canonical destination and rechecks the parent, existing destination, and no-follow temporary-file handle before the atomic replacement. On macOS, granting extended ACL entries are rejected on every checked ancestor, parent, existing file, and empty temporary file; a private-looking 0700/0600 mode does not override that result. If the normal configuration root or one of its ancestors is group/world-writable, preflight intentionally refuses to start authentication. Repair that directory’s permissions yourself or set GARMIN_SESSION_TOKEN_FILE/--output to a fresh owner-private application directory; the plugin will not silently chmod a shared or broadly writable configuration tree.

On Windows, the implicit account path prefers the current user’s local LOCALAPPDATA root over redirected roaming APPDATA. Keep any explicit destination beneath the current user’s local OS profile/config root and use a fresh dedicated subtree; UNC/network destinations are not supported. From the longest matching Windows special-folder root down to the session parent, every component must have a protected DACL owned by the current SID with exactly one current-SID FullControl rule. Missing components are created atomically with that DACL; non-exact existing components and every reparse point are rejected rather than rewritten. The empty temporary file receives the same exact file DACL before credential bytes are written, and the entire directory chain plus file ACL is verified again when a session is read. Marker-only directories from earlier implementations are not trusted; migrate to a fresh dedicated subtree.

Multiple accounts: one isolated process per account

The supported runtime model is one account per process and one independently initialized session per process. Give each dsh, Codex, Claude Code, or other MCP process its own GARMIN_USERNAME, GARMIN_REGION, and GARMIN_ACCOUNT (or an explicit GARMIN_SESSION_TOKEN_FILE). Each process can lazily use its implicit account session path and use the supported browser MFA bootstrap. The real China-region account chain has been verified end to end.

Do not copy one session file to another process, and do not let simultaneous processes share one file. Garmin refresh tokens may rotate; concurrent writers can otherwise invalidate or overwrite each other’s credentials. For example, use aliases such as personal-dsh, personal-codex, and personal-claude, with an independently initialized session for each one. Do not point another runtime at the same file through a symbolic link or a differently cased path alias.

The processes may share one GARMIN_FIT_DOWNLOAD_DIR parent: the plugin creates a separate account subdirectory from each configured region and email. This also keeps cn and global accounts with the same email from colliding. For one MCP entry, ordinary Garmin questions use that entry as the default. For two entries, name them garmin-cn and garmin-global; mention the server name only when the intended account is ambiguous.

This is process isolation, not an in-process account selector or a multi-tenant authorization system. Do not expose one shared MCP process to mutually untrusted users; per-user access control has not been implemented. Switching accounts inside one conversation and automatic cross-account sync remain on the roadmap.

FIT downloads

download_garmin_activity_fit accepts only an activity ID; the model cannot choose an arbitrary output path. Garmin’s original activity ZIP is downloaded to a private temporary location, size-checked, and required to contain exactly one valid FIT file. Given a configured parent directory <base>, the result is written as <base>/GARMIN_FIT_<cn|global>_<normalized-email>/<activityId>.fit without overwriting an existing file. The cn or global component comes from GARMIN_REGION. Here <normalized-email> is derived safely from the configured email: a normal email address remains recognizable, while path separators, control characters, and other unsafe filename characters are normalized before the account directory is created. The user locates the file from the configured parent plus this rule. The tool returns only activityId, fileName, sizeBytes, and sha256; it does not return the parent, account directory, email, or full path. ZIP/FIT bytes never enter model context.

The parent directory has no default and must be chosen explicitly through GARMIN_FIT_DOWNLOAD_DIR. It is required only when using this tool; if unset, the tool fails before writing any file and all other Garmin tools remain available. Multiple account processes can safely share the same parent because their region-and-normalized-email subdirectories are isolated, including when the same email is used for both Garmin China and Garmin International. Existing GARMIN_FIT_<email> directories are not migrated automatically; new downloads use the region-prefixed directory while old files remain in place.

Garmin’s “original” export is not guaranteed to be FIT. If the archive has no single valid FIT entry, the tool fails safely instead of renaming another format.

4. Run

npx --legacy-peer-deps=false @deepseek-ai/dsh web

Open http://127.0.0.1:3080. The plugin is loaded when Settings → Plugins → Plugin list shows plugin-garmin-connect as mounted & enabled. Then try: “How was my sleep last night?” or “Show me my last 5 runs.”

5. Integration Test (optional, source checkout only)

The integration script is a development aid and is not included in the npm tarball. From a source checkout with development dependencies installed, you can run it after configuring .env:

npm run test:integration

The script checks read-only APIs and exits non-zero if any check fails. It does not create, update, or delete workouts or other Garmin data.

By default it hides the account identifier and prints only counts/status, not activity or health values. Set GARMIN_INTEGRATION_VERBOSE=true only when you explicitly want normalized details in your local terminal output.

📋 Click to expand sample output ``` 🔌 Garmin Connect Integration Test Domain : garmin.com User : configured (identifier hidden) Date : 2026-08-18 Scope : read-only (workout creation/update/deletion is not tested) ── 1. Authentication ── ✅ Password login successful ── 2. Activities ── ✅ Got 3 activities ── 3. Sleep ── ✅ Sleep data loaded ── 4. Steps ── ✅ Step data loaded ── 5. Heart Rate ── ✅ Heart-rate data loaded ── 6. Weight / Body Composition ── ✅ Body-composition data loaded ── 7. Workout Library ── ✅ Got 5 workout templates ── 8. User Profile ── ✅ Profile loaded 🏁 Integration test complete: 8 passed, 0 failed. Write operations were intentionally not tested. ```

Security

Credentials are used locally to authenticate directly with Garmin Connect and are never returned by an AI tool.

Credential Resolution Order

1. Plugin config values (set on the plugin row in a profile patch / `--patch` overlay)
   ↓ fallback
2. Environment variables (.env / shell)
   ↓ fallback
3. Schema defaults

Best Practices

Practice Status
Environment-variable and secret-marked configuration are supported ✅
.env is in .gitignore ✅
Account identifier and credentials marked with role('secret') in Cordis schema ✅
Local dsh Web MFA bridge ✅ Supported; loopback only; real China-region MFA chain passed locally
CLI serve and MCP URL elicitation ✅ Supported; same-machine shared runtime and owner-only session persistence
Legacy CLI login --browser / canary ⚠️ Playwright diagnostics only; not an authentication fallback
DI v2 sessions bind username, region, and profileIdHash; legacy two-field sessions remain compatible ✅
Independently initialized per-process session files support isolated multi-account setups ✅
Access refresh is preemptive; idempotent GET replay is limited to once and writes are never replayed ✅
Tool outputs never include raw credentials ✅
FIT bytes and local/account paths stay on the host; the model receives only activity/file name/size/hash ✅
In-memory cache reduces API calls (rate-limit protection) ✅

Session Tokens

Session-token authentication remains supported, but tokens are credentials and must not appear in agent output or trajectory logs. For that reason this plugin does not expose authentication, MFA submission, or token export as AI-callable tools. If you already have a validated owner-only DI v2 or compatible legacy session file, dsh/MCP can read it through GARMIN_SESSION_TOKEN_FILE; the runtime does not need the account password. The DI file binds normalized username and region as well as profileIdHash; legacy unbound oauth1/oauth2 files remain readable for compatibility. Creating a new MFA session through the dsh Web bridge, serve, or MCP URL elicitation is a supported same-machine workflow. Because Garmin refresh tokens may rotate, never concurrently share or copy one session file across dsh, Codex, Claude Code, or other processes.

Use with Other AI Coding Agents (MCP)

This plugin also ships as a standalone MCP (Model Context Protocol) server, so you can use the same Garmin tools with OpenAI Codex, Claude Code, Claude Desktop, Cursor, Windsurf, WorkBuddy, ZCode, and any other MCP-compatible client — no DeepSeek Harness required.

Current availability: the standalone MCP entry point is included in npm 0.1.5 and later. A local checkout remains useful for development.

Build the local server first:

git clone https://github.com/Likenttt/garmin-connect-plugin-for-dsh.git
cd garmin-connect-plugin-for-dsh
npm install
npm run build

Replace /absolute/path/to/garmin-connect-plugin-for-dsh in the examples with the checkout’s actual absolute path.

The MCP process needs an email, explicit region, and local account alias. A session-file path is optional: when omitted, the server derives an owner-only path from GARMIN_ACCOUNT. Make these values and any FIT parent directory available to the client process:

export GARMIN_USERNAME='[email protected]'
export GARMIN_REGION='global'
export GARMIN_ACCOUNT='personal'
export GARMIN_FIT_DOWNLOAD_DIR='/absolute/path/to/garmin-fit-parent'
# Optional override; otherwise accounts/personal.session.json is used.
# export GARMIN_SESSION_TOKEN_FILE='/absolute/path/to/personal.session.json'

Do not put a password or MFA code in these variables. If a tool encounters a missing, expired, or rejected session, or an explicit MFA/CAPTCHA browser challenge, and the client advertises MCP URL elicitation, the tool call returns a random local 127.0.0.1 sign-in URL. Open that URL, finish Garmin login/MFA and profile confirmation in the browser, wait for the completion notification, then retry the original request. The server does not automatically replay it, so a write can never be duplicated by this flow. Clients without URL elicitation receive the equivalent trusted-terminal fallback command:

If a legacy GARMIN_PASSWORD is still present, successful password-only login continues to work. Only positive MFA input/form or active CAPTCHA markup is converted to the same browser-recoverable MCP authentication state. The SDK’s ambiguous no-ticket text, a wrong password, HTTP 401, and network failures are not treated as MFA; the password and upstream error text never enter the tool result.

garmin-connect-auth serve --account personal --region global --open

If that MCP entry explicitly sets GARMIN_SESSION_TOKEN_FILE, export the same value in the trusted terminal or append --output with that same destination. The fallback error deliberately does not echo the local path into model context. After serve commits a changed, account-matching session, retrying the tool hot-loads that exact file snapshot in the already-running MCP process; an MCP restart is not required. An unchanged rejected file, an expired replacement, or a file for another account is never probed again. If an inline GARMIN_SESSION_TOKEN was explicitly rejected, this safe replacement also supersedes it in memory; the rejected inline credential is not retried.

The authentication page, not the MCP tool or model, receives the password and MFA code. Protect the resulting session file and FIT directory because they can grant account access or contain precise location and health data. Each simultaneously running client process needs its own alias/session; do not copy or concurrently share one file across Codex, Claude Code, dsh, or another client. Browser MFA is supported as described above; the China-region real-account chain has been verified end to end.

OpenAI Codex (app, CLI, and IDE extension)

Codex clients on the same host share ~/.codex/config.toml. The recommended setup forwards credential variable names from the environment instead of copying their values into TOML. With the variables above available to the Codex process, add this entry to ~/.codex/config.toml:

[mcp_servers.garmin-connect]
command = "node"
args = ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"]
env_vars = ["GARMIN_USERNAME", "GARMIN_REGION", "GARMIN_ACCOUNT", "GARMIN_SESSION_TOKEN_FILE", "GARMIN_FIT_DOWNLOAD_DIR"]

# Read tools can run normally; Codex asks before local-file and Garmin writes.
default_tools_approval_mode = "writes"

This entry uses the session assigned only to this Codex process. When Codex advertises URL elicitation, it may surface the local sign-in link described above; otherwise initialize the same alias with garmin-connect-auth serve. The password/MFA code stays on Garmin’s page. Do not reuse a session already assigned to dsh, Claude Code, or another running process. For China and International accounts, add separately configured entries named, for example, garmin-cn and garmin-global. They may reuse the same FIT parent; output is automatically isolated under that account’s region-and-normalized-email subdirectory.

The Codex process must inherit the exported variables. If the desktop app was launched outside that shell, add the server through Settings → MCP servers and provide its environment there, or launch it through your usual secret-aware environment. Values entered in Settings are local credentials; protect the resulting configuration file.

For a trusted-project-only setup, put the same table in .codex/config.toml inside that project. Restart the Codex client after editing the file, then inspect the saved configuration:

codex mcp list
codex mcp get garmin-connect

Inside Codex CLI, use /mcp to verify that the server is active and inspect its tools. The official Codex MCP documentation also covers the Settings UI and codex mcp add command.

Claude Code

Garmin is normally a personal server, so user scope is a good default. The following bash/zsh example keeps the session contents out of ~/.claude.json; only the owner-only file path is configured:

claude mcp add-json --scope user garmin-connect \
  '{"type":"stdio","command":"node","args":["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],"env":{"GARMIN_USERNAME":"${GARMIN_USERNAME}","GARMIN_REGION":"${GARMIN_REGION:-global}","GARMIN_ACCOUNT":"${GARMIN_ACCOUNT:-default}","GARMIN_SESSION_TOKEN_FILE":"${GARMIN_SESSION_TOKEN_FILE}","GARMIN_FIT_DOWNLOAD_DIR":"${GARMIN_FIT_DOWNLOAD_DIR}"}}'

This server uses a session assigned specifically to this Claude Code process. If the client does not surface MCP URL elicitation, initialize it with the trusted-terminal serve command; password/MFA input remains on Garmin’s page. Register a differently named server and provide a distinct independently initialized session file for each additional process or account. Do not copy another process’s session. The servers may reuse the same FIT parent directory.

Use --scope local instead if the server should be available only in the current project. Keep the path variables available whenever you launch Claude Code, then verify the connection:

claude mcp get garmin-connect
claude mcp list

Inside Claude Code, /mcp shows connection status and the exposed tools. See the official Claude Code MCP documentation for scope and .mcp.json details. Do not commit personal Garmin credentials in a project-scoped configuration.

Using the tools in Codex or Claude Code

Once garmin-connect reports as connected, ask naturally; the client selects the MCP tool. If tool selection is ambiguous, explicitly say “use the garmin-connect MCP server.” For example:

Workout creation still follows the enforced two-call confirmation flow: the first call only previews, and creation requires your approval plus the returned one-time confirmationId.

Claude Desktop

Edit ~/Library/Application Support/Claude/claude_desktop_config.json (macOS) or %APPDATA%\Claude\claude_desktop_config.json (Windows):

{
  "mcpServers": {
    "garmin-connect": {
      "command": "node",
      "args": ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],
      "env": {
        "GARMIN_USERNAME": "[email protected]",
        "GARMIN_REGION": "global",
        "GARMIN_ACCOUNT": "personal",
        "GARMIN_SESSION_TOKEN_FILE": "/absolute/path/to/personal.session.json",
        "GARMIN_FIT_DOWNLOAD_DIR": "/absolute/path/to/garmin-fit-parent"
      }
    }
  }
}

Restart Claude Desktop. You’ll see a 🔌 icon indicating the tools are loaded. Try: “Show my last 5 runs” or “Preview a threshold workout”.

Cursor

Add the same mcpServers.garmin-connect object shown above to the workspace’s .cursor/mcp.json, using the absolute lib/mcp.js path.

Windsurf

Open Windsurf Settings → Cascade → MCP Servers, or edit ~/.codeium/windsurf/mcp_config.json, and add the same mcpServers.garmin-connect object shown above.

WorkBuddy

WorkBuddy Desktop supports local MCP servers at user and project scope. For personal Garmin data, prefer the user-level ~/.workbuddy/mcp.json. Open Plugins → MCP Servers → Configure MCP, or edit that file directly, and add:

{
  "mcpServers": {
    "garmin-connect": {
      "command": "/absolute/path/to/node",
      "args": ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],
      "env": {
        "GARMIN_USERNAME": "[email protected]",
        "GARMIN_REGION": "global",
        "GARMIN_ACCOUNT": "personal",
        "GARMIN_SESSION_TOKEN_FILE": "/absolute/path/to/personal.session.json",
        "GARMIN_FIT_DOWNLOAD_DIR": "/absolute/path/to/garmin-fit-parent"
      }
    }
  }
}

Use command -v node on macOS/Linux or where node on Windows to find the absolute Node.js executable; GUI applications may not inherit an nvm shell path. In JSON on Windows, use forward slashes such as C:/.../node.exe, or escape each backslash as \\. Leave out type in WorkBuddy’s local-command format. Save the file and confirm that the server status turns green, then start with a read-only request. See the official WorkBuddy MCP guide.

The session file in this entry must be independently initialized; a client that does not surface URL elicitation uses the trusted-terminal serve command. WorkBuddy and the model never receive the password/MFA code. Add another named mcpServers entry with a separate session file per account. Entries may share the same FIT parent directory because region-and-email account subdirectories are automatic.

ZCode

Open Settings → MCP Servers → New MCP Server, choose User scope and stdio, then enter the same absolute Node.js command, lib/mcp.js argument, and Garmin environment variables. Alternatively, edit the native user config at ~/.zcode/cli/config.json:

To test this release directly from npm, use an absolute npx path as the command and these arguments instead of a checkout’s lib/mcp.js:

-y --package dsh-plugin-garmin-connect garmin-connect-mcp

Do not configure GARMIN_PASSWORD; with a missing session, the first read-only tool call can exercise ZCode’s URL-elicitation path. Keep the explicit owner-only GARMIN_SESSION_TOKEN_FILE shown below.

{
  "mcp": {
    "servers": {
      "garmin-connect": {
        "command": "/absolute/path/to/node",
        "args": ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],
        "env": {
          "GARMIN_USERNAME": "[email protected]",
          "GARMIN_REGION": "global",
          "GARMIN_ACCOUNT": "personal",
          "GARMIN_SESSION_TOKEN_FILE": "/absolute/path/to/personal.session.json",
          "GARMIN_FIT_DOWNLOAD_DIR": "/absolute/path/to/garmin-fit-parent"
        }
      }
    }
  }
}

ZCode can also import an existing Codex or Claude Code MCP entry. Its generic ~/.agents/mcp.json support uses the mcpServers shape, but if the same scope’s .zcode config contains any MCP server, ZCode skips that .agents file rather than merging it. See the official ZCode MCP guide.

The session file in this entry must be independently initialized; a client that does not surface URL elicitation uses the trusted-terminal serve command. ZCode and the model never receive the password/MFA code. Add another named server with a separate session file per account. Servers may share the same FIT parent directory because region-and-email account subdirectories are automatic.

These configurations have been checked against both clients’ published schemas; an end-to-end WorkBuddy/ZCode smoke test with a real Garmin account has not yet been recorded.

The Claude Desktop, Cursor, Windsurf, WorkBuddy, and ZCode JSON examples store the sensitive session-file path in their client configuration, but not the session contents, password, or MFA code. Restrict those files’ permissions and never commit them. The Codex and Claude Code examples forward path variables instead. MCP results can place sleep, heart-rate, weight, activity, and location data in the selected model’s context; review that client’s data controls and keep activity detail at compact unless precise expanded data is necessary. FIT bytes and the complete local/account path remain on the MCP host. Only the activity ID, file name, size, and hash enter model context; locate the file using your configured parent and the documented account-directory rule.

With npm 0.1.5 or later, the local node …/lib/mcp.js command can be replaced with:

npx -y --package dsh-plugin-garmin-connect garmin-connect-mcp

Manual Run

# Run the MCP server (stdio); the account session path is derived lazily.
GARMIN_USERNAME=xxx \
GARMIN_ACCOUNT=personal \
GARMIN_REGION=global \
GARMIN_FIT_DOWNLOAD_DIR=/absolute/path/to/garmin-fit-parent \
node lib/mcp.js

The MCP server exposes the same 10 tools and argument semantics as the dsh plugin: activities, sleep, steps, heart rate, weight, workout-library templates, profile, running skills, local FIT download, and workout preview/creation. No AI-callable tool accepts a password/MFA code or exports a session token. Browser authentication is an out-of-band local URL elicitation, and the user must retry the original tool after completion.

Architecture

┌─────────────────────────────────────────┐
│         DeepSeek Harness (dsh)          │
│                                         │
│  ┌───────────────────────────────────┐  │
│  │     dsh-plugin-garmin-connect     │  │
│  │                                   │  │
│  │  ┌─────────┐    ┌─────────────┐  │  │
│  │  │  Config  │───▶│ GarminClient│  │  │
│  │  │ (Schema) │    │  (cached)   │  │  │
│  │  └─────────┘    └──────┬──────┘  │  │
│  │                        │         │  │
│  │  ┌─────────────────────▼───────┐ │  │
│  │  │      Tool Registry (10)     │ │  │
│  │  │  • get_garmin_activities    │ │  │
│  │  │  • get_garmin_sleep         │ │  │
│  │  │  • get_garmin_steps         │ │  │
│  │  │  • get_garmin_heart_rate    │ │  │
│  │  │  • get_garmin_weight        │ │  │
│  │  │  • get_garmin_workouts      │ │  │
│  │  │  • get_garmin_profile       │ │  │
│  │  │  • get_running_skill_advice │ │  │
│  │  │  • download activity FIT    │ │  │
│  │  │  • create_garmin_workout    │ │  │
│  │  └─────────────────────────────┘ │  │
│  └───────────────────────────────────┘  │
│               Cordis Runtime            │
└────────────────┬────────────────────────┘
                 │
      ┌──────────┴──────────┐
      ▼                     ▼
connect.garmin.com    MCP Server (stdio)
connect.garmin.cn     → Claude Desktop / Claude Code /
                        Codex / Cursor / Windsurf /
                        WorkBuddy / ZCode

Target architecture for two-step verification

The architecture gives dsh Web, MCP clients, and the CLI one shared local authentication runtime while keeping Garmin credentials out of AI conversations:

┌──────────────────┐  ┌──────────────────┐  ┌──────────────────┐
│ dsh Web          │  │ MCP tool call    │  │ CLI serve        │
│ region/auth state│  │ URL elicitation  │  │ system browser   │
└────────┬─────────┘  └────────┬─────────┘  └────────┬─────────┘
         └─────────────────────┼─────────────────────┘
                               ▼
          LocalAuthBroker + EmbeddedAuthController
                               │
                               ▼
          random one-shot 127.0.0.1 bridge
          flowId + CSRF + strict CSP + 10-minute TTL
                               │ embeds the exact regional page
                               ▼
          official Garmin GAuth iframe (cn / global)
          email, password, MFA, and CAPTCHA stay here
                               │
                               │ one-time ticket + original exact service
                               ▼
          Host validates origin / iframe / CSRF / ticket / service
                               │
                               ▼
          regional DI exchange → profile probe → user confirmation
                               │
                               ▼
          atomically persist an owner-only DI v2 session
          bound to account, region, and profile; never shared by processes
                               │
                               ▼
          GarminClient hot-load / safe refresh
                               │
                               ▼
          user explicitly retries the original tool call

The non-negotiable boundaries are:

[!NOTE] This is the target architecture and the boundary followed by the current release-supported implementation. A real China-region MFA → exact ticket/service → DI exchange → profile confirmation → private session write → fresh-client read chain has passed locally. A real International-region MFA → DI exchange → profile confirmation → private session write also passed. Real refresh-token rotation and complete URL-elicitation UX in more MCP clients remain ongoing compatibility coverage. The design is same-machine loopback only, not a remote, multi-user, or hosted authentication service.

Development

# Clone & install
git clone https://github.com/Likenttt/garmin-connect-plugin-for-dsh.git
cd garmin-connect-plugin-for-dsh
npm install

# Build
npm run build

# Watch mode
npm run dev

# Run tests
npm test

Project Structure

src/
├── index.ts          # Plugin entry point (Cordis apply function)
├── config.ts         # Configuration schema with env-var resolution
├── client.ts         # Garmin API wrapper with caching
├── account-session.ts # Implicit per-account session destination
├── auth.ts           # Private-SSO authentication flow with local MFA callback
├── auth-cli.ts       # Trusted local serve and legacy diagnostic commands
├── browser-auth-canary.ts # Isolated Chrome DI setup/canary core
├── embedded-auth-runtime.ts # Shared Web/CLI/MCP ticket-to-session runtime
├── local-auth-broker.ts # One-shot loopback/system-browser broker
├── di-session.ts     # DI runtime validation, refresh, and safe GET replay
├── session-store.ts  # Strict session-file loading and atomic private writes
├── darwin-private-acl.ts # Darwin extended-ACL verification
├── windows-private-acl.ts # Owner-only Windows SID/DACL enforcement
├── fit-export.ts     # Bounded, non-overwriting FIT extraction from original ZIP
├── tool-service.ts   # Shared tool behavior for dsh and MCP
├── mcp.ts            # Standalone MCP adapter for Codex/Claude Code/other clients
├── mcp-auth.ts       # URL elicitation, completion notification, and fallback
├── mcp-shutdown.ts   # Bounded stdio/signal cleanup for MCP auth
├── knowledge/
│   ├── running-skills.ts  # 8 workout types + 4 compact training philosophies
│   └── workout-schema.ts  # Workout definition → Garmin JSON builder
├── tools/
│   └── index.ts      # Tool definitions & registration (10 tools)
└── utils/
    ├── errors.ts      # Safe public errors and upstream-log redaction
    ├── cache.ts       # In-memory TTL/LRU cache with single-flight refresh
    ├── date.ts        # Local calendar-date parsing
    ├── path.ts        # FIT parent-directory expansion and resolution
    └── format.ts      # Raw-data → LLM-friendly formatters

Publishing & Distribution

The package is a standard dsh bundle: package.json declares dsh.bundle.patch → cordis.patch.yml, and files ships the compiled lib/, .env.example, both READMEs, and the patch file.

npm run build   # prepublishOnly also runs this automatically
npm publish

After publishing, users install with a single command:

npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add dsh-plugin-garmin-connect

Distribution notes:

Roadmap

License

MIT

Acknowledgements

Product names and logos belong to their respective owners and are shown only to describe interoperability.
